Plastic board printer
With 10 years of accumulated technology and experience, the machine is more practical and durable.
Language
With 10 years of accumulated technology and experience, the machine is more practical and durable.
HYUNVAN UV PRINTING WITH KT BOARD
HYY-UV6090
FLATBED SIZE: 600*900MM
SAMPLE PRINTING SIZE IS 400*600MM
MATERIAL: 5MM KT BOARD
TECHNICAL DAT
Mode Type | Flatbed UV Printer MT-UV6090pro |
Print head | XP600 Printheads |
Number of Nozzles | 2 printheads |
Printing Technology | Unidirectional, Bidirectional |
Resolution | 360dpi * 720dpi * 1440dpi |
Color | CMYK + W/CMYKLcLm+W/CMYKLclm+Varnish |
Printing Height | UP to 200mm |
Printing machine Weight | 180kg |
Printing Machine Size | 1600mm * 1700mm * 700mm |
UV Curing System | Water-cooled LED UV Curing Lamp |
Lifting Function | Intelligently Carriage Lifting Function, Automatic Printing Height Adjusting And Measure Detect Function |
Printing Platform | Vacuum Suction Platform |
Printing Resolution | 360dpi X 720dpi, 720dpi X 1440dpi |
Printing Speed | 4 pass, 7.5 m²/h, 6.5 m²/h; |
| 6 pass, 6.5 m²/h, 5.5 m²/h; |
| 8 pass, 5.2 m²/h, 4.1 m²/h; |
| 12 pass, 3.7 m²/h, 3.2 m²/h; |
Media handling | Glass, Acrylic, Ceramic Tile, Aluminum, Iphone Case, Plastic, Foam Board, Wallpaper, Wall Art, Sign Advertising, Metal, Paper, Wood, MDF, Furniture, Card, Marble, Golf Products, Gift & Promotion Products, Leather, PU, PMMA, PVC, PP, PE, PTFE, Plexiglass, Panels, Ceiling, Organic Board, Corrugated, Chevron Board, Fiberboard, Brick, Stone, Home & Office Decoration, Electric Appliances Panel, Pottery & Porcelain Tile, 3C Product, Oil Painting, Fresco, Sliding Door, Wedding Photography, Mark And Signs, Exhibition, Etc...... |
Ink Type | Import Soft LED UV Curing Ink / Rigid LED UV Curing Ink (Without VOC) |
Bulk Ink supply System | 1.5 Liter X 6 Colors |
Output Life | Indoor 10years, Outdoor 3years |
Interface | High Speed USB Transmission |
Power Voltage | AC220/110±10, 50HZ-60HZ |
Control System | Control System |
RIP Software | Photoprint |
Printer Demension | Printing Environment |
File Formats | Tiff, Jpg, Eps, Pdf |
PRODUCT FEATURES
1) Item Model: HYY-UV6090pro
2) Machine Body Materal: Aluminum Alloy and Stainless Steel
3) Printhead: L1440 Printheads
4) Resolution: 600 , 900 , 1200 , 1800 , 2400 dpi
5) Size of Ink Droplet: 7PL
6) RIP Software: Photoprint/ Caldera(Option)
Packing size: L 1700* W 1800* H 1000mm
Weight:350kg
