HYUNVAN High Quality UV printer printing on KT board
Professional and thoughtful customer services are provided by Suzhou Hyunvan Intellitech Co.,Ltd..



TECHNICAL PARAMETERS


Model    HYY-UV2013    HYY-UV2513    HYY-UV2518    HYY-UV2030    HYY-UV2530    HYY-UV2540    HYY-UV3030    HYY-UV3050

Machine Dimensions    L:2150mm    L:2150mm    L:2750mm    L:3900mm    L:4900mm    L:4490mm    L:3900mm    L:5900mm

W:3930mm    W:4430mm    W:4430mm    W:4430mm    W:4430mm    W:4430mm    W:4930mm    W:4930mm

H:1400mm    H:1400mm    H:1400mm    H:1400mm    H:1400mm    H:1400mm    H:1400mm    H:1400mm

machine Weight    1200kg    1400kg    1500kg    1700kg    1900kg    2000kg    2100kg    2300kg

Printing size:    2000mm*1250mm    2500mm*1250mm    2500mm*1800mm    2050mm*3000mm    2500mm*3000mm    2500mm*4000mm    3000mm*3000mm    3000mm*5000mm

Printhead    Style    Ricoh Gen5

Ink Droplet Size    7-35PL

Grey grade    8 Grade

Printhead QTY    2-24pcs

Printhead    Configuration    2-8 printerheads    9-24 printerheads

Draft Mode    20-80m2/h    80-180m2/h

Production Mode    14-56m2/h    56-120m2/h

High Quality Mode    10-40m2/h    40-90m2/h

Printing Resolution    720*2400 dpi (6pass)

Media's Max Thickness    0-100m Customized    thickness is acceptable

Flatbed capacity    100kg/m2

Color Configuration     C,M,Y,K,Lc,Lm,W,V

Clean way    Postitive Pressure    Cleaning

Curing Method    LED UV water-cooling Lamp

Lens hood    Metal integrated lens    hood,protect eyes

Data Interface    USB3.0/Network Interface

Power Supply    Single    Phase AC220V,50/60Hz.14A,3KW(Print power 1500w,Adsorption platform 1500w)

RIP Software    PhotoPrint,UltraPrint,PhotoMangent

Image Format    TIFF,JPEG,CMX,AI,PSD,PS,PDF,EPS

Color Control    International    ICC standard with adjusting function for profiles and density

Print mode    Single/Double

Print material    Glass, acrylic, metal,    wood, plastic, paper, ceramic tile, leather,

PVC/PP/ABS/PET/KT    board,aluminum composite panel

Operation System    Win7(x64),Win10(x64)

Working environment    Temperature:15-30C,    Humidity:40%-70%


Advantages

1.Accept non-standard customization ,  accept super large, super high, super heavy, cylindrical, special-shaped, super high-speed machine customization

2.Color Accuracy- The international high-end color management system is adopted to ensure the color accuracy of each picture, and the independent ICC can be customized for you individually.

3.With 10 years of accumulated technology and experience, the machine is more practical and durable. Leading quality.  Successfully sold to Europe, America, Middle East, Southeast Asia and other countries, and welcomed by customers from domestic and worldwide.

4.One-stop purchase of more than ten kinds of printing formats,  6000M2 production workshop, more than ten kinds of printing formats, and 3 kinds of ultra-high-precision printing nozzles. One-stop purchase is more assured.



FAQ

1.What about the After-sales service ?
1. Provide customers with a systematic site layout proposal to ensure a smooth installation. 2. Provide free on-site training at the factory and second review training at the installation site; 3. The standard warranty period on average is one year. However, HYUNVAN would like to offer extra warranty period (consitions apply), lifetime maintenance.  4. We HYUNVAN can send engineers to help customers install the machines, train workers, but buyer should offer ticket charge, boarding and lodging .
2.What are the requirements of installation environment?
Power supply: 220V, 50Hz, reliable grounding, set the protection device of over-current and over-voltage, preferably with stable 5KVA power; Environment: with temperature 20~25℃， humidity 50%~80%, dustless, no directly sunlight, flat and stable floor surface.
3.How to deal with the surface of glass and ceramic tile? How to spray?
Glass and ceramic tile are both the commonly used materials. We have special coating for this materials and with perfect effect.  There are air pump spray, hand brushing, rolling spraying and various methods.
