Improve the working efficiency of UV printers-map link

Under normal circumstances, if a picture is printed at 300dpi with a size of 2.4m*1.2m, the picture exported from CDR is about 800MB-900MB, which is very big for the running speed of the computer. The test, especially if you want to process multiple such large images in batches, the computer that is almost configured will directly crash.

HYUNVAN UV Printing machine manufactuer has many experience on it. We believe that many technicians have encountered this problem. If the computer is in good condition, it will end in about 4 minutes. If the computer is poor, the UV printer mapping link can be solved in 8-12 minutes, which is 1-2 times worse. time. So to extend it, the pictures to be processed every day and the pictures to be processed every year are at least 10,000 minutes of wasted time.

If you encounter a customer looking at the equipment on-site, you need to make a picture, which will greatly waste each customer’s time. If the machine crashes seriously, it will also give the customer a bad impression that their equipment is not working. If the customer does not purchase the equipment because of this link, So the cost paid by the sales department, e-commerce department and other departments for this is wasted. This is a very big loss to the enterprise.

So how to improve and shorten the link of UV printer's map to effectively improve production efficiency? Mainly through two means to solve.


Hardware: Configure high-performance hardware for the computer. It is recommended to use 4 cores for the CPU, 8G above DDR3 1666 for the memory, and 1G-2G for the graphics card. If you have higher requirements for speed, you can also install a solid state drive to improve the overall system Operating speed.

Motherboard B150

CPU Intel Core i5 6500

Graphics card Colorful 2G independent display

Memory Kingston 8G DDR3 1666

Hard disk 256G solid state + 2T mechanical

Power 500W

The display has a resolution of 1920*1080 and above

CD-ROM drive

Personnel: The proofing computer and UV printer technicians put the software program on a hard disk separately, and put other materials on other disks. Do not mix them. At the same time, clean up the computer's garbage and cache at least once a day to improve the computer's operating speed.

Through the above two methods, you can effectively shorten the time wasted in the UV printer mapping link and improve the operating efficiency of UV printers.


1.What about the After-sales service ?
1. Provide customers with a systematic site layout proposal to ensure a smooth installation. 2. Provide free on-site training at the factory and second review training at the installation site; 3. The standard warranty period on average is one year. However, HYUNVAN would like to offer extra warranty period (consitions apply), lifetime maintenance.  4. We HYUNVAN can send engineers to help customers install the machines, train workers, but buyer should offer ticket charge, boarding and lodging .
2.What are the requirements of installation environment?
Power supply: 220V, 50Hz, reliable grounding, set the protection device of over-current and over-voltage, preferably with stable 5KVA power; Environment: with temperature 20~25℃, humidity 50%~80%, dustless, no directly sunlight, flat and stable floor surface.
3.How long does the print-head working life?
A print-head can be used 2 years in regular working conditions.
